17" Sunlight Readable Monitor
Fill out the form below to request a quote.
- 1,000 nits Brightness Produces Clear, Sharp Images Even in Direct Bright Sunlight
- TRU-Tuff Ensures Maximum Shock & Vibration Resistance
- High Resolution: 1280 x 1024 (SXGA)
- Internal Rear Speaker
- Lockable On-Screen Display (OSD) Controls
- Auto Re-Start After Power Loss
- Can Be Customized to Meet Your Needs – 3-Year Warranty
SUNLIGHT READABLE MONITORS
The SRM-17S-DB-H are 17″ sunlight readable monitors. They feature at least 1000 nits brightness and a 4:3 aspect ratio. We design the SRM-17 Series monitors for use in direct sunlight. Consequently, they are also perfect for other high ambient-light conditions. They utilize state-of-the-art LED backlights. The models in this series produce at least 1,000 nits brightness. In contrast, this is over 3 to 5 times brighter than standard monitors. For example, standard monitors are only 200-300 nits brightness. Therefore, the result is amazingly bright screen. This will provide you with crystal-clear images, even with bright, direct sunlight on the face of the screen.
RUGGED INDUSTRIAL MONITORS
The SRM-17S-DB-H Sunlight Readable monitors are extremely rugged. For instance, we build them with true industrial-grade components. Furthermore, they receive our exclusive TRU-Tuff treatment. The TRU-Tuff process includes RTV silicone on all connections and critical components. Additionally, all wires are dressed, tie-wrapped and secured. Lastly, we apply ThreadLock to all screws. The ABS enclosure will ensure shock and vibration resistance for this rugged 1000 nit monitor.
HIGH BRIGHTNESS MONITOR WITH EXTREME OPERATING TEMPERATURES
We design the SRM-17S-DB-H 17″ High Brightness Display Series to operate in nearly any environmental conditions. Whether in frigid conditions or blazing heat, these sunlight displays will survive and thrive. To clarify, these monitors will operate in temperatures down to -30°F (-35°C). They will also withstand brutal heat. Moreover, operating temperatures go up to 185°F (85°C). The rugged ABS enclosure assures these 17″high brightness displays will provide years of reliable imaging performance. Specifically, typical MTBF for these monitors is 50,000 hours.
HIGH BRIGHT MONITORS DEPLOYED WORLDWIDE
Our 17″ sunlight readable monitors have been deployed in a wide range of demanding industries. For example, military, law enforcement, and entertainment benefit. They are also found in inspection, oil and gas, and transportation. Additionally, see how pipeline, manufacturing and drone industries also enjoy TRU-Vu displays. TRU-Vu monitors are backed by our full 3-Year Warranty. This ensures you of many years of reliable service.
In conclusion, see our full line-up of industrial-grade Sunlight Readable and Daylight Readable. This highlights all of our high brightness monitors. Additionally, you’ll find the sunlight readable touch screens in all the sizes and configurations available. Browse similar sized monitors and filter by the features important to you. TRU-Vu can provide modified or Custom OEM LCD Displays. Private Label Monitors are also an option if you have very specific requirements. Use our Advanced Search Tool which enables you to filter by your required specifications. We are here to help. Feel free to give us a call so that our technical experts may assist you in finding the best display for your application.
Scroll left & right to view full table.
|LCD Panel||17” Color LCD; LED Backlights|
|Resolution||1280 x 1024 (SXGA)|
|Viewable Area||13.30” (W) x 10.64” (H) (337.9 x 270.3 mm)|
|Display Colors||16.7 Million|
|Aspect Ratio||4:3 (5:4)|
|Ambient Light Sensor||Standard|
|Viewing Angle||160˚ (H) x 140˚ (V)|
|Response||5 msec Trf|
|Control||OSD (On-Screen Display) via Front Panel Pushbuttons|
|Video Inputs||VGA, S-Video, Composite (BNC), NTSC/PAL|
|Power Requirement||12 VDC (2.1mm Barrel Plug); 90-240 VAC via Included Power Brick|
|Power Consumption||50 Watts|
|Mounting||75x75mm Rear VESA Hole Pattern (Optional Tabletop Base)|
|Operating Temperature||-30˚ to +185˚F (-35˚ to +85˚C)|
|Shock||50 G (20 msec, ½ sine)|
|Vibration||1.5G RMS 10-200 HZ|
|Dimensions||14.88 (W) x 12.50” (H) x 1.91” (D) (378 x 317.5 x 48.6mm)|
|Weight||5.78 lbs. (2.62 kg)|
Specifications subject to change without notice.
- 90-240 VAC Power Supply
- VGA Cable
- Audio Cable (3.5mm Headphone Jack to RCA)
- HDMI Input
- DisplayPort Input
- Tabletop Base
- Automated Ambient Light Sensor
- Protective/Anti-Glare Glass
- Waterproof NEMA 4 Enclosure (VMW-17C-SS or SRMW-17C-H))
- BNC Loop-Thru Video Input
- 24 VDC Operation
- Optical Bonding (SRMOB-19-SERIES)
- Rack Mount Bracket MB-Rack-17
- Touch Screen (VMT-17 Series)
- Open-Frame Configuration
- Private Label
- Other Customer – Specific Modifications
